| Description |
“Classical” angled bar rack (a) and angled bar rack with bars in the streamwise direction (b). |
| Author | |
| Source |
Raynal, S., et al. 2014. Streamwise bars in fish-friendly angled trashracks. s.l. : Journal of Hydraulic Research Vol. 52, No. 3 (2014), pp. 426–431, 2014. |
